ATC CDA2 Mk 2 CD player DAC Pre-amplifier

ATC CDA2 Mk 2 CD player, DAC and Pre-amplifier.

What we Say:


The ATC CDA2 Mk 2 is an integrated CD player, DAC and pre-amplifier. It offers the possibility of a one box plus active speakers system that will sound great. grated amps in the ATC range. It features 2 line level analogue inputs 3 digital inputs as well as having a built in headphone amplifier. The ATC CDA2 Mk 2 has both balanced (XLR) and unbalanced (RCA) connections.


See attached technical specification.

Partnering equipment:

The CDA2 can be connected to any pair of active loudspeakers or a power amp using balanced or unbalanced cables. The P1 or P2 or SCM40A are the bvious choices.


Get in touch with us to hear it for yourself.

Enquire about the ATC CDA2 Mk 2 CD player DAC Pre-amplifier >

Contact me when this ex-demo becomes available >

What they say:

CDA2 – CD Pre-Amplifier DAC


  • All-discrete class-A pre-amplifier with balanced and unbalanced outputs.
  • Two analogue inputs via RCA/phononand one via 3.5mm mini-jack.
  • High performance CD Player.
  • Premium AKM 32-bit DAC.
  • USB digital input supporting up to 384kHz PCM data and native DSD256.*
  • Headphone amp featuring discrete output stage.
  • Handmade in England.
  • 6 year warranty.**

*DSD256 support via PC only (up to DSD128 via Mac).
** TWO years on CD mechanism.


1kHz < 0.0015% (-96dB)
10kHz < 0.003% (-90dB)
Frequency Response (20Hz–20kHz): +/- 0.2dB


Frequency Response (-3dB): < 2 Hz – > 280 kHz
Distortion (1kHz): <0.0008% / 102dB
Input sensitivity for 2V Output: Aux inputs 600mV 3.5mm inputs 400mV
Maximum Output Level: Phono 9.2V r.m.s XLR 18.4V r.m.s.
Overload Capacity: 13dB
Input Impedance: 14k Ohms
Output Impedance: 10 Ohms
S+N/N Ratio:
Wide Band >96dB
DIN >108dB
IEC “A” >112dB
Absolute Phase:
Phono Zero Degrees
XLR Zero Degrees, Pin 2 Hot
Output XLR CMRR (100Hz – 10kHz): >60dB

DIGITAL INPUTS Optical and Coaxial

<0.001% at all supported sample rates
44.1kHz, 48.0kHz, 88.2kHz, 96.0kHz, 192.0kHz*
* 192kHz supported via coaxial input only


<0.001% at all supported sample rates
44.1kHz, 48.0kHz, 88.2kHz, 96.0kHz, 176.4kHz, 192.0kHz, 352.8kHz, 384kHz

Optical and Coaxial: 16bit and 24bit
USB: 16bit, 24bit and 32bit

Frequency Response -1dB: < 10Hz – 50kHz
Supported DSD Rates:
Windows DSD64, DSD128 and DSD256
MacOS DSD64 and DSD128


Dimensions (HxWxD): 90 x 445 x 330mm (3.5˝ x 17.5˝ x 13˝)
Weight: 7kg / 15.4Ilbs
