Chord Electronics Mojo 2 DAC and Headphone amplifier

Chord Electronics Mojo 2 DAC and headphone amplifier.

What we Say:

The Chord Electronics Mojo 2 DAC and headphone amplifier is the second generation Mojo product. The original Mojo is the most successful DAC and headphone amplifier on the market and has been ever since it’s launch. Mojo 2 moves the performance on significantly and also provides extra functionality. The new Mojo 2 features 4 buttons compared to the 3 on the Mojo. A new menu button allows access to a range of new features made possible by the new super powerful DSP chip on board. These new features include lossless DSP equalisation functions which allows the user to tailor the sound to their taste.

The Chord Electronics Mojo 2 also features new connectivity making it more flexible than ever before. Mojo 2 is equipped with a USB-C connector making connection to the latest generation of Android phones much easier. Mojo 2 also features a new dual data coax connector. You can use this to connect the dual coax output of the Hugo M scaler as a digital input. This can feed the Mojo 2 with digital data right up to 768kHz

The Mojo has a bigger battery than Mojo 1. It also features improved battery management.

For more Chord Electronics products available from DNA Audio.

https://dnaaudio.co.uk/product_brand/chord-electronics/

https://chordelectronics.co.uk/mojo-2

The following link is a really great use guide to the features of Mojo 2.

Enquire about the Chord Electronics Mojo 2 DAC and Headphone amplifier >

Contact me when this ex-demo becomes available >

What they say:

Portable DAC/Headphone Amplifier
Simply without equal

MOJO 2

Mojo 2 is the most advanced DAC/headphone amplifier in the world.  It plays your favourite music with class-leading detail and clarity, right up to studio-grade levels.

DAC AND HEADPHONE AMPLIFIER IN ONE

The British designed, engineered and built Mojo 2 is the most advanced portable DAC and headphone amplifier in the world.

Distinctly different from all other devices, Mojo 2 uses proprietary British digital audio technology perfected over more than two decades, coupled to a powerful ‘FPGA’ processor. The result is class-leading sound quality both on the move or at home, with the power to effortlessly drive any headphones. For music just as the artist intended, Mojo 2 brings you closer to the music than any other portable.



UNIQUE BENEFITS

Unrivalled digital audio processing; powerful ‘FPGA’ technology
Additional USB-C data input for fast data-transfer
Fully transparent ‘Ultra HD’ digital signal processing EQ, tailoring the sound to you
Take Mojo 2 wireless when adding the Poly streamer/server (2 TB)

Proudly made in Britain from aircraft-grade aluminium. Anodised, bead-blasted, precision CNC milled. Jett black finish.

UNIQUE FPGA TECHNOLOGY

For more than 20 years, Chord Electronics has exclusively used powerful programmable (FPGA) circuits with custom coding to provide the most advanced digital-to-analogue conversion performance in the world. With digital audio technologies perfected over two decades, Mojo 2 contains more digital audio know-how than any other small DAC, resulting in unrivalled sound quality, all backed by peerless technical measurements from the lab.

COMPATIBLE WITH POLY FOR STREAMING

Completely compatible with our Wireless streaming module Poly, Poly allows for wireless integration to your system…



Find more here: https://chordelectronics.co.uk/product/poly/

  • ACoaxial input
  • BUSB-C input
  • CMicro-USB input
  • DMicro-USB charging input
  • EOptical input
  • FCharge status LED
  • GMenu button (new)
  • HVolume down/menu ‘-‘
  • IVolume up/menu ‘+’
  • JPower button
  • KHeadphone outputs (2x 3.5mm)

Mojo 2 offers several ways to connect to digital devices, including smartphones, tablets and laptops, plus two 3.5 mm headphone outputs, meaning two can listen simultaneously. Digital inputs include fast-transfer USB-C, Micro-USB, optical and coaxial, with charging via a separate dedicated Micro-USB input.

Mojo polychromatic light-up buttons offer simple control with an additional visual guide to the device’s settings. A new menu button offers navigation through a new range of features, including the all-important completely transparent UHD DSP function.

Mojo 2 brings exciting new features for music lovers.

Improved FPGA: more resolution, power and efficiency
Improved battery: FPGA-controlled management plus improved capacity
New menu function
‘UHD’ DSP: advanced EQ adjustment for headphones, file formats and personal taste
Improved WTA filtering: 40 DSP cores for better transparency and lower noise
High-speed USB-C input
Two 3.5 mm headphone outputs
Wireless-ready – simply add the Poly streamer/server
  • Five digital inputs: coaxial, dual-data coax, optical, Micro-USB and USB-C
  • Dynamic range 125.7 dB A wt.
  • Noise 2.7 uV A wt., no measurable noise floor modulation
  • Distortion and noise 0.00027 % at 2.5 V 300 ohms
  • Power output 1 % distortion:

Mojo 2 offers several ways to connect to digital devices, including smartphones, tablets and laptops, plus two 3.5 mm headphone outputs, meaning two can listen simultaneously. Digital inputs include fast-transfer USB-C, Micro-USB, optical and coaxial, with charging via a separate dedicated Micro-USB input.

Mojo polychromatic light-up buttons offer simple control with an additional visual guide to the device’s settings. A new menu button offers navigation through a new range of features, including the all-important completely transparent UHD DSP function.

Mojo 2 brings exciting new features for music lovers.

Improved FPGA: more resolution, power and efficiency
Improved battery: FPGA-controlled management plus improved capacity
New menu function
‘UHD’ DSP: advanced EQ adjustment for headphones, file formats and personal taste
Improved WTA filtering: 40 DSP cores for better transparency and lower noise
High-speed USB-C input
Two 3.5 mm headphone outputs
Wireless-ready – simply add the Poly streamer/server
  • Five digital inputs: coaxial, dual-data coax, optical, Micro-USB and USB-C
  • Dynamic range 125.7 dB A wt.
  • Noise 2.7 uV A wt., no measurable noise floor modulation
  • Distortion and noise 0.00027 % at 2.5 V 300 ohms
  • Power output 1 % distortion:
  • 90 mW 300 ohms (5.2 V RMS)
  • 600 mW 30 ohms (4.2 V RMS)
  • 0.06 ohms output impedance
