Esoteric G-02X Master Clock Generator
Esoteric G-02X Master Clock Generator.
What we Say:
The Esoteric G-02X Master Clock Generator is the ideal upgrade for your Esoteric CD/SACD player or Streamer. The Esoteric G-02X can be used to upgrade several units
The Master clock of the digital source is crucial to the performance. The more accurate it is the better the performance will be. Inaccuracy of the mater clock is called Jitter and the greater the jitter the greater the distortion in the signal produced. This is why Esoteric pay great attention to the quality of the master clock. The G-02X features a heated compartment to keep the clock generator at a constant temperature. This helps the clock to work at a stable frequency and contributes to the clock precision of 0.01 parts per million. This high degree of precision helps to reduce phase or timing related noise by approx 3dB over the previous model.
Two main types of error can occur in clocks, they are the frequency precision and frequency stability. Both have an effect on overall performance. To make sure you are getting the most out of your Esoteric digital source get in touch to hear what a Master Clock Generator can do.
Esoteric make 3 different models with the G-02X being the starting point in the range. The G-02X has 8 clock outputs and one clock input. Add it to a K-03XD or other source components for improved performance.
For other Esoteric products available from DNA Audio please visit.
For more information on the G-02X please visit.Enquire about the Esoteric G-02X Master Clock Generator >
Contact me when this ex-demo becomes available >
What they say:
Master Clock Generator
The core of the unit features a custom OCXO (Oven Controlled Crystal Oscillator) newly developed by ESOTERIC that is comprised of an oven that maintains a constant internal temperature, a crystal oscillator, and an oscillating circuit. This OCXO was designed for high audio quality based on the wisdom of the Grandioso series to provide an excellent center frequency precision (±0.01 ppm Typ), and reduces phase noise by approximately 3 dB* compared to previous model.
*Measured at an offset frequency of 100 Hz
The unit adopts the “Wide Range Clock Buffer Amplifiers” developed for the Grandioso G1. These discrete circuits utilize high-speed transistors with excellent performance at high frequencies and are separated for each output terminal to contribute to improved sound quality.
The G-02X has the “Adaptive Zero Ground” circuitry inherited from the Grandioso G1 between the internal OCXO and the buffer amplifiers. The “Adaptive Zero Ground” mode actively drives the ground signal to 0 volts and greatly reduces noise (random jitter) caused by variation in the ground voltage. The user can select between the adaptive mode and the normal mode, for different sound characteristics according to their listening preferences.
A newly-designed power supply is adopted to maximize the performance of the new “Wide Range Clock Buffer Amplifiers”, with the amplifier and power supply divided into blocks to ensure drive that is both clean and powerful. A toroidal transformer is used as the main transformer and a dedicated El core transformer is used for control. A series of multiple capacitors are used for the ripple filter circuit and Schottky barrier diodes are used for quick response to support fast digital processing.
The G-02X can supply a clock signal to a maximum of eight devices. Output can be switched ON and OFF for each terminal. The unit has four 10 MHz sine wave clock output terminals. The other four output terminals (A x 2 and B x 2) enable clock signals to be output at 100 kHz, 10 MHz (square wave), and the basic frequency of 44.1 kHz/48 kHz, up to a maximum frequency of 22.5792 MHz/24.576 MHz, and separate output frequencies can be set for each terminal.
- External 10 MHz Input for External Clocks
- Milled Brass Gold Plated BNC Terminals
- Preheat Function for Internal OCXO
- Organic EL Display
